Pilier Guide de Haute Précision
High Precision Guide Pillar is designed for advanced tooling and mold systems where exact alignment and repeatable movement are essential. Produced from premium bearing steel and finished through ultra-precision grinding processes, it delivers exceptional straightness, surface quality, and wear resistance. The high-accuracy guiding surface helps reduce positional deviation and supports stable operation over extended production periods. Commonly applied in semiconductor tooling, medical molds, electronic component manufacturing, and precision automation equipment, it ensures dependable performance in demanding environments.
- Delivers Exceptional Positioning Accuracy: Ensures precise alignment for critical applications.
- Serves Precision Manufacturing Industries: Suitable for advanced technical production.
- Maintains Long Term Dimensional Stability: Preserves accuracy throughout extended operation.
- Supports Ultra Fine Tolerances: Enables highly controlled component movement.
Description du produit
Introduction
High Precision Guide Pillar is a premium mold guiding component designed for applications requiring exceptional positioning accuracy, smooth movement, and long-term dimensional stability. It is widely used in precision injection molds, tamponnement, semiconductor tooling, medical device molds, and high-accuracy automation equipment. The guide pillar ensures precise alignment between moving mold components, helping improve product consistency and manufacturing reliability.
Manufactured from high-quality bearing steel such as SUJ2 or GCr15, the High Precision Guide Pillar undergoes advanced heat treatment, precision grinding, super-finishing, and polishing processes. These manufacturing technologies provide outstanding hardness, Résistance à l’usure, straightness, and surface quality. The precision-ground guiding surface minimizes clearance variation and maintains highly accurate movement throughout extended production cycles.
High Precision Guide Pillars are suitable for precision mold bases, connector molds, optical component molds, medical equipment molds, electronic product molds, and industrial automation systems. Available in a wide range of diameters, lengths, and tolerance grades, they can satisfy both standard industrial requirements and custom engineering projects. OEM and ODM manufacturing services are available based on customer drawings and specifications.
Caractéristiques techniques
| Paramètre | Spécification |
|---|---|
| Nom du produit | Pilier Guide de Haute Précision |
| Matériel | SUJ2 / GCr15 Acier à Paliers |
| Finition de surface | Sol de Super Précision |
| Dureté | HRC 58-62 |
| Plage de diamètres | Ø8 mm – Ø120 mm |
| Plage de longueur | 50 mm – 1800 mm |
| Type de guidage | Guidage d’alignement de précision |
| Droiture | ≤0.002 mm/100 mm |
| Traitement de surface | Chrome dur optionnel |
| Type d’installation | Ajustement pressé / Montage personnalisé |
| Pente de précision | Ultra haute précision |
| Conditions de fonctionnement | Exploitation industrielle continue |
| Durée de service | Utilisation industrielle à long terme |
| Personnalisation | OEM & ODM Available |
Trois aspects clés de la personnalisation, Adapté à vos besoins
Adapter différentes méthodes de personnalisation pour répondre à divers besoins.
Fabrication de précision, Qualité excellente
Atteint une précision de positionnement exceptionnelle
Manufactured to tight tolerances, ensuring highly precise alignment for demanding applications where dimensional consistency is critical to product quality.
Idéal pour les industries de fabrication de précision
Widely used in medical, electronic, semiconductor, and optical tooling systems requiring reliable guidance and exact component positioning.
Maintient une stabilité dimensionnelle supérieure
Advanced material processing helps preserve geometric accuracy under continuous operation, supporting dependable long-term guiding performance.
Prend en charge les exigences de tolérance ultra-fine
Designed for applications requiring extremely small clearance variations, enabling accurate movement and improved assembly precision.
Service raffiné, Délai de livraison réduit
De la revue de conception à la livraison, Nous proposons un suivi personnalisé dédié tout au long du processus.
Consultation → Fournir des plans → une revue de conception & Devis → traitement des commandes → inspection qualité → livraison à temps → suivi après-vente
Nos avantages
Soutenu par plus de 25 ans d’expérience en ingénierie, Notre équipe propose des services complets — de la conception personnalisée des moules et l’usinage de précision à la production à grande échelle — soutenus par un système d’assurance qualité robuste et un service client proactif. Certifié sous ISO9001, ISO14001, et IATF 16949, Nous visons continuellement l’excellence en matière de qualité, Innovation, et la satisfaction client.
Plus de 100,000 Unités en stock, avec un envoi en 2 heures pour les produits standards.
Mise en œuvre d’un système d’inspection en trois étapes — vérification initiale des matériaux, Inspection en cours de processus, et inspection finale.
Inventaire important et délais rapides, Garantir une livraison à temps avec une inspection 100 % des produits.
Champ d’application
Le choix privilégié dans divers secteurs.
FAQ
What is a High Precision Guide Pillar?
A High Precision Guide Pillar is a precision alignment component used in molds, Ceci, and automation systems to ensure accurate positioning and smooth guiding performance.
What are the benefits of a High Precision Guide Pillar?
It provides superior alignment accuracy, excellent dimensional stability, reduced wear, smooth movement, and reliable long-term operation.
What materials are commonly used for High Precision Guide Pillars?
High Precision Guide Pillars are typically manufactured from SUJ2 or GCr15 bearing steel, offering high hardness, Résistance à l’usure, and durability.
Can High Precision Guide Pillars be customized?
Oui. Custom diameters, lengths, Tolérances, surface treatments, mounting configurations, and precision grades can be produced according to customer specifications.
Where are High Precision Guide Pillars commonly used?
They are widely used in precision injection molds, tamponnement, semiconductor tooling, medical device molds, electronic component molds, optical product molds, et équipements d’automatisation industrielle.
